Hubble Deep Field

2008/9 Schools Wikipedia Selection. Related subjects: Space (Astronomy)

The Hubble Deep Field.
The Hubble Deep Field.

The Hubble Deep Field (HDF) is an image of a small region in the constellation Ursa Major, based on the results of a series of observations by the Hubble Space Telescope. It covers an area 15 arcminutes across, equivalent in angular size to a tennis ball (about 65mm) at a distance of 100 metres and a two-millionth of our sky. The image was assembled from 342 separate exposures taken with the Space Telescope's Wide Field and Planetary Camera 2 over ten consecutive days between December 18 and December 28, 1995.

The field is so small that only a few foreground stars in the Milky Way lie within it; thus, almost all of the 3,000 objects in the image are galaxies, some of which are among the youngest and most distant known. By revealing such large numbers of very young galaxies, the HDF has become a landmark image in the study of the early universe, and it has been the source of almost 400 scientific papers since it was created.

Three years after the HDF observations were taken, a region in the south celestial hemisphere was imaged in a similar way and named the Hubble Deep Field South. The similarities between the two regions strengthened the belief that the universe is uniform over large scales and that the Earth occupies a typical region in the universe (the cosmological principle). In 2004 a deeper image, known as the Hubble Ultra Deep Field (HUDF), was constructed from a total of eleven days of observations. The HUDF image is the deepest (most sensitive) astronomical image ever made at visible wavelengths.

Conception

The dramatic improvement in Hubble's imaging capabilities after corrective optics were installed encouraged attempts to obtain very deep images of distant galaxies
The dramatic improvement in Hubble's imaging capabilities after corrective optics were installed encouraged attempts to obtain very deep images of distant galaxies

One of the key aims of the astronomers who designed the Hubble Space Telescope was to use its high optical resolution to study distant galaxies to a level of detail that was not possible from the ground. Positioned above the atmosphere, Hubble avoids atmospheric airglow allowing it to take more sensitive visible and ultraviolet light images than can be obtained with seeing-limited ground-based telescopes (when good adaptive optics correction becomes available in the visible, 10 m ground-based telescopes may become competitive). Although the telescope's mirror suffered from spherical aberration when the telescope was launched in 1990, it could still be used to take images of more distant galaxies than had previously been obtainable. Because light takes billions of years to reach Earth from very distant galaxies, we see them as they were billions of years ago; thus, extending the scope of such research to increasingly distant galaxies allows a better understanding of how they evolve.

After the spherical aberration was corrected during Space Shuttle mission STS-61 in 1993, the now excellent imaging capabilities of the telescope were used to study increasingly distant and faint galaxies. The Medium Deep Survey (MDS) used the WFPC2 to take deep images of random fields while other instruments were being used for scheduled observations. At the same time, other dedicated programs focused on galaxies that were already known through ground-based observation. All of these studies revealed substantial differences between the properties of galaxies today and those that existed several billion years ago.

Up to 10% of the HST's observation time is designated as Director's Discretionary (DD) Time, and is typically awarded to astronomers who wish to study unexpected transient phenomena, such as supernovae. Once Hubble's corrective optics were shown to be performing well, Robert Williams, the then director of the Space Telescope Science Institute, decided to devote a substantial fraction of his DD time during 1995 to the study of distant galaxies. A special Institute Advisory Committee recommended that the WFPC2 be used to image a "typical" patch of sky at a high galactic latitude, using several optical filters. A working group was set up to develop and implement the project.

Target selection

The HDF is at the centre of this image, one degree across, which shows the unremarkable nature of this patch of sky.
The HDF is at the centre of this image, one degree across, which shows the unremarkable nature of this patch of sky.

The field selected for the observations needed to fulfil several criteria. It had to be at a high galactic latitude, because dust and obscuring matter in the plane of the Milky Way's disc prevents observations of distant galaxies. The target field had to avoid known bright sources of visible light (such as foreground stars), and infrared, ultraviolet and X-ray emissions, to facilitate later studies at many wavelengths of the objects in the deep field, and also needed to be in a region with a low background infrared ' cirrus', the diffuse, wispy infrared emission believed to be caused by warm dust grains in cool clouds of hydrogen gas ( H I regions).

These criteria considerably restricted the field of potential target areas. It was further decided that the target should be in Hubble's 'continuous viewing zones' (CVZs)—the areas of sky which are not occulted by the Earth or the moon during Hubble's orbit. The working group decided to concentrate on the northern CVZ, so that northern-hemisphere telescopes, such as the Keck telescopes and the Very Large Array, could conduct follow-up observations.

Twenty fields satisfying all of these criteria were initially identified, from which three optimal candidate fields were selected, all within the constellation of Ursa Major. Radio snapshot observations ruled out one of these fields because it contained a bright radio source, and the final decision between the other two was made on the basis of the availability of guide stars near the field: Hubble observations normally require a pair of nearby stars on which the telescope's Fine Guidance Sensors can lock during an exposure, but given the importance of the HDF observations, the working group required a second set of back-up guide stars. The field that was eventually selected is located at a right ascension of 12h 36m 49.4s and a declination of +62° 12′ 48″.

Observations

The HDF was located in Hubble's northern Continuous Viewing Zone, as shown by this diagram.
The HDF was located in Hubble's northern Continuous Viewing Zone, as shown by this diagram.

Once a field had been selected, an observing strategy had to be developed. An important decision was to determine which filters the observations would use; WFPC2 is equipped with forty-eight filters, including narrowband filters isolating particular emission lines of astrophysical interest, and broadband filters useful for the study of the colours of stars and galaxies. The choice of filters to be used for the HDF depended on the ' throughput' of each filter— the total proportion of light that it allows through— and the spectral coverage available. Filters with bandpasses overlapping as little as possible were desirable.

In the end, four broadband filters were chosen, centred at wavelengths of 300 nm (near-ultraviolet), 450 nm (blue light), 606 nm (red light) and 814 nm (near- infrared). Because the quantum efficiency of Hubble's detectors is quite low at 300 nm, the noise in observations at this wavelength is primarily due to CCD noise rather than sky background; thus, these observations could be conducted at times when high background noise would have harmed the efficiency of observations in other passbands.

Images of the target area in the chosen filters were taken over ten consecutive days, during which Hubble orbited the Earth about 150 times. The total exposure times at each wavelength were 42.7 hours (300 nm), 33.5 hours (450 nm), 30.3 hours (606 nm) and 34.3 hours (814 nm), divided into 342 individual exposures to prevent significant damage to individual images by cosmic rays, which cause bright streaks to appear when they strike CCD detectors.

Data processing

A section of the HDF about 14 arcseconds across in each of the four wavelengths used to construct the final version: 300 nm (top left), 450 nm (top right), 606 nm (bottom left) and 814 nm (bottom right)
A section of the HDF about 14 arcseconds across in each of the four wavelengths used to construct the final version: 300 nm (top left), 450 nm (top right), 606 nm (bottom left) and 814 nm (bottom right)

The production of a final combined image at each wavelength was a complex process. Bright pixels caused by cosmic ray impacts during exposures were removed by comparing exposures of equal length taken one after the other, and identifying pixels that were affected by cosmic rays in one exposure but not the other. Trails of space debris and artificial satellites were present in the original images, and were carefully removed.

Scattered light from the Earth was evident in about a quarter of the data frames. This was removed by taking an image affected by scattered light, aligning it with an unaffected image, and subtracting the unaffected image from the affected one. The resulting image was smoothed, and could then be subtracted from the bright frame. This procedure removed almost all of the scattered light from the affected images.

Once the 342 individual images were cleaned of cosmic-ray hits and corrected for scattered light, they had to be combined. Scientists involved in the HDF observations pioneered a technique called ' drizzling', in which the pointing of the telescope was varied minutely between sets of exposures. Each pixel on the WFPC2 CCD chips recorded an area of sky 0.09 arcseconds across, but by changing the direction in which the telescope was pointing by less than that between exposures, the resulting images were combined using sophisticated image-processing techniques to yield a final angular resolution better than this value. The HDF images produced at each wavelength had final pixel sizes of 0.03985 arcseconds.

The data processing yielded four monochrome images, one at each wavelength. The combining of these into the full colour images released to the public was a fairly arbitrary process, with one image designated as each of red, green and blue, and the three images combined to give a colour image. Because the wavelengths at which the images were taken do not correspond to the wavelengths of red, green and blue light, the colours in the final image only give an approximate representation of the actual colours of the galaxies in the image; the choice of filters for the HDF (and the majority of Hubble images) was primarily designed to maximize the scientific utility of the observations rather than to create colours corresponding to what the human eye would actually perceive.

Contents of the Deep Field

The final images revealed a plethora of distant, faint galaxies. About 3,000 distinct galaxies could be identified in the images, with both irregular and spiral galaxies clearly visible, although some galaxies in the field are only a few pixels across. In all, the HDF is thought to contain fewer than ten galactic foreground stars; by far the majority of objects in the field are distant galaxies.

There are about fifty blue point-like objects in the HDF. Many seem to be associated with nearby galaxies, which together form chains and arcs: these are likely to be regions of intense star formation. Others may be distant quasars. Astronomers initially ruled out the possibility that some of the point-like objects are white dwarfs, because they are too blue to be consistent with theories of white dwarf evolution prevalent at the time. However, more recent work has found that many white dwarfs become bluer as they age, lending support to the idea that the HDF might contain white dwarfs.

Scientific results

Details from the HDF illustrate the wide variety of galaxy shapes, sizes and colours found in the distant universe.
Details from the HDF illustrate the wide variety of galaxy shapes, sizes and colours found in the distant universe.

The HDF data provided extremely rich material for cosmologists to analyse and as of 2005, almost 400 papers based on the HDF have appeared in the astronomical literature. One of the most fundamental findings was the discovery of large numbers of galaxies with high redshift values.

As the universe expands, more distant objects recede from the Earth faster, in what is called the Hubble Flow. The light from very distant galaxies is significantly affected by the cosmological redshift. While quasars with high redshifts were known, very few galaxies with redshifts greater than 1 were known before the HDF images were produced. The HDF, however, contained many galaxies with redshifts as high as 6, corresponding to distances of about 12 billion light-years . (Due to redshift the most distant objects in the HDF are not actually visible in the Hubble images; they can only be detected in images of the HDF taken at longer wavelengths by ground-based telescopes.)

The HDF galaxies contained a considerably larger proportion of disturbed and irregular galaxies than the local universe; galaxy collisions and mergers were more common in the young universe as it was much smaller than today. It is believed that giant elliptical galaxies form when spirals and irregular galaxies collide.

The wealth of galaxies at different stages of their evolution also allowed astronomers to estimate the variation in the rate of star formation over the lifetime of the universe. While estimates of the redshifts of HDF galaxies are somewhat crude, astronomers believe that star formation was occurring at its maximum rate 8–10 billion years ago, and has decreased by a factor of about 10 since then.

Another important result from the HDF was the very small number of foreground stars present. For years astronomers had been puzzling over the nature of dark matter, mass which seems to be undetectable but which observations implied made up about 90% of the mass of the universe. One theory was that dark matter might consist of Massive Astrophysical Compact Halo Objects ( MACHOs) — faint but massive objects such as red dwarfs and planets in the outer regions of galaxies. The HDF showed, however, that there were not significant numbers of red dwarfs in the outer parts of our galaxy.

Subsequent observations

The Hubble Deep Field South looks very similar to the original HDF, demonstrating the Cosmological Principle.
The Hubble Deep Field South looks very similar to the original HDF, demonstrating the Cosmological Principle.
The Hubble Ultra Deep Field further corroborates this. The smallest, reddest galaxies, about 100, are some of the most distant to have been imaged in an optical telescope.
The Hubble Ultra Deep Field further corroborates this. The smallest, reddest galaxies, about 100, are some of the most distant to have been imaged in an optical telescope.

The HDF is a landmark in observational cosmology and much still remains to be learned from it. Since 1995, the field has been observed by many ground-based telescopes as well as some further space telescopes, at wavelengths from radio to X-ray.

Very-high redshift objects were discovered within the HDF using a number of groundbased telescopes, in particular via the James Clerk Maxwell Telescope. The high redshift of these objects means that they cannot be seen in visible light and generally are detected in infrared or submillimetre wavelength surveys of the HDF instead.

Important space-based observations have included those by the Chandra X-ray Observatory and the Infrared Space Observatory (ISO). X-ray observations revealed six sources in the HDF, which were found to correspond to three elliptical galaxies: one spiral galaxy, one active galactic nucleus and one extremely red object, thought to be a distant galaxy containing a large amount of dust absorbing its blue light emissions.

ISO observations indicated infrared emission from 13 galaxies visible in the optical images, attributed to large quantities of dust associated with intense star formation. Ground-based radio images taken using the VLA revealed seven radio sources in the HDF, all of which correspond to galaxies visible in the optical images.

1998 saw the creation of an HDF counterpart in the southern celestial hemisphere: the HDF-South. Created using a similar observing strategy, the HDF-S was very similar in appearance to the original HDF. This supports the cosmological principle that at its largest scale the universe is homogenous.
