Whale song

2008/9 Schools Wikipedia Selection. Related subjects: Mammals

Humpback whales are well known for their songs

Whale song is the sound made by whales to communicate.

The word " song" is used in particular to describe the pattern of regular and predictable sounds made by some species of whales, notably the humpback. This is included with or in comparison with music, and male humpback whales have been described as, "inveterate composers," of songs, "'strikingly similar' to human musical traditions".

The mechanisms used to produce sound vary from one family of cetaceans to another. Marine mammals, such as whales, dolphins, and porpoises, are much more dependent on sound for communication and sensation than are land mammals, as other senses are of limited effectiveness in water. Sight is limited for marine mammals because of the way water absorbs light. Smell is also limited, as molecules diffuse more slowly in water than in air, which makes smelling less effective. In addition, the speed of sound in water is roughly four times that in the atmosphere at sea level. Because sea mammals are so dependent on hearing to communicate and feed, environmentalists and cetologists are concerned that they are being harmed by the increased ambient noise in the world's oceans caused by ships and marine seismic surveys.

Production of sound

Humans produce sound by expelling air through the larynx. The vocal cords within the larynx open and close as necessary to separate the stream of air into discrete pockets of air. These pockets are shaped by the throat, tongue, and lips into the desired sound.

Cetacean sound production differs markedly from this mechanism. The precise mechanism differs in the two major suborders of cetaceans: the Odontoceti ( toothed whales—including dolphins) and the Mysticeti ( baleen whales—including the largest whales, such as the Blue Whale).

Odontocete whale sound production

Idealized dolphin head showing the regions involved in sound production. This image was redrawn from Cranford (2000).

Toothed whales do not make the long, low-frequency sounds known as the whale song. Instead they produce rapid bursts of high-frequency clicks and whistles. Single clicks are generally used for echolocation whereas collections of clicks and whistles are used for communication. Though a large pod of dolphins will make a veritable cacophony of different noises, very little is known about the meaning of the sound. Frankell quotes one researcher characterizing listening to such a school as like listening to a group of children at a school playground.

The multiple sounds themselves are produced by passing air through a structure in the head rather like the human nasal passage called the phonic lips. As the air passes through this narrow passage, the phonic lip membranes are sucked together, causing the surrounding tissue to vibrate. These vibrations can, as with the vibrations in the human larynx, be consciously controlled with great sensitivity. The vibrations pass through the tissue of the head to the melon, which shapes and directs the sound into a beam of sound for echolocation. Every toothed whale except the sperm whale has two sets of phonic lips and is thus capable of making two sounds independently. Once the air has passed the phonic lips it enters the vestibular sac. From there the air may be recycled back into the lower part of the nasal complex, ready to be used for sound creation again, or passed out through the blowhole.

The French name for phonic lips—museau de singe—translates to "monkey lips," which the phonic lip structure is supposed to resemble. New cranial analysis using computed axial and single photon emission computed tomography scans in 2004 showed that, at least in the case of bottlenose dolphins, air may be supplied to the nasal complex from the lungs by the palatopharyngeal sphincter, enabling the sound creation process to continue for as long as the dolphin is able to hold their breath.

Odontocete Whale Sound Levels

The frequency of toothed whale sounds ranges from 40 Hz to 325 kHz. A list of typical levels is shown in the table below.

Mysticete whale sound production

Baleen whales do not have phonic lip structure. Instead they have a larynx that appears to play a role in sound production, but it lacks vocal cords and scientists remain uncertain as to the exact mechanism. The process, however, cannot be completely analogous to humans because whales do not have to exhale in order to produce sound. It is likely that they recycle air around the body for this purpose. Cranial sinuses may also be used to create the sounds, but again researchers are currently unclear how.

Mysticete Whale Sound Levels

The frequency of baleen whale sounds ranges from 10 Hz to 31 kHz. A list of typical levels is shown in the table below.

Purpose of whale-created sounds

While the complex and haunting sounds of the Humpback Whale (and some Blue Whales) are believed to be primarily used in sexual selection (see section below), the simpler sounds of other whales have a year-round use. While many toothed whales are capable of using echolocation to detect the size and nature of objects, this capability has never been demonstrated in baleen whales. Further, unlike some fish such as sharks, a whale's sense of smell is not highly developed. Thus, given the poor visibility of aquatic environments and the fact that sound travels so well in water, sounds audible to humans may play a role in navigation. For instance, the depth of water or the existence of a large obstruction ahead may be detected by loud noises made by baleen whales.

The singing of whale songs for aesthetic enjoyment, personal satisfaction, or 'for art's sake', is, "an untestable question in scientific terms.".

The song of the Humpback Whale

Humpback Whale song spectrogram,
— Play audio (OGG format, 57 kB)

Two groups of whales, the Humpback Whale and the subspecies of Blue Whale found in the Indian Ocean, are known to produce the repetitious sounds at varying frequencies known as whale song. Marine biologist Philip Clapham describes the song as "probably the most complex in the animal kingdom".

Male Humpback Whales perform these vocalizations only during the mating season, and so it is surmised the purpose of songs is to aid sexual selection. Whether the songs are a competitive behavior between males seeking the same mate, a means of defining territory or a "flirting" behaviour from a male to a female is not known and the subject of on-going research. Males have been observed singing while simultaneously acting as an "escort" whale in the immediate vicinity of a female. Singing has also been recorded in competitive groups of whales that are composed of one female and multiple males.

Interest in whale song was aroused by researchers Roger Payne and Scott McVay after the songs were brought to their attention by a Bermudian named Frank Watlington who was working for the US government at the SOFAR station listening for Russian submarines with underwater hydrophones off the coast of the island. The songs follow a distinct hierarchical structure. The base units of the song (sometimes loosely called the " notes") are single uninterrupted emissions of sound that last up to a few seconds. These sounds vary in frequency from 20 Hz to 10 kHz (the typical human range of hearing is 20 Hz to 20 kHz). The units may be frequency modulated (i.e., the pitch of the sound may go up, down, or stay the same during the note) or amplitude modulated (get louder or quieter). However the adjustment of bandwidth on a spectrogram representation of the song reveals the essentially pulsed nature of the FM sounds.

A collection of four or six units is known as a sub- phrase, lasting perhaps ten seconds (see also phrase (music)). A collection of two sub-phrases is a phrase. A whale will typically repeat the same phrase over and over for two to four minutes. This is known as a theme. A collection of themes is known as a song. The whale will repeat the same song, which last up to 30 or so minutes, over and over again over the course of hours or even days. This " Russian doll" hierarchy of sounds has captured the imagination of scientists.

All the whales in an area sing virtually the same song at any point in time and the song is constantly and slowly evolving over time. For example, over the course of a month a particular unit that started as an "upsweep" (increasing in frequency) may slowly flatten to become a constant note. Another unit may get steadily louder. The pace of evolution of a whale's song also changes—some years the song may change quite rapidly, whereas in other years little variation may be recorded.

Idealized schematic of the song of a Humpback Whale.
Redrawn from Payne, et al. (1983)

Whales occupying the same geographical areas (which can be as large as entire ocean basins) tend to sing similar songs, with only slight variations. Whales from non-overlapping regions sing entirely different songs.

As the song evolves it appears that old patterns are not revisited. An analysis of 19 years of whale songs found that while general patterns in song could be spotted, the same combinations never recurred.

Humpback Whales may also make stand-alone sounds that do not form part of a song, particularly during courtship rituals. Finally, Humpbacks make a third class of sound called the feeding call. This is a long sound (5 to 10 s duration) of near constant frequency. Humpbacks generally feed cooperatively by gathering in groups, swimming underneath shoals of fish and all lunging up vertically through the fish and out of the water together. Prior to these lunges, whales make their feeding call. The exact purpose of the call is not known, but research suggests that fish do know what it means. When the sound was played back to them, a group of herring responded to the sound by moving away from the call, even though no whale was present.

Some scientists have proposed that humpback whale song may serve an echolocative purpose, but has been subject to disagreement.

Other whale sounds

Most baleen whales make sounds at about 15–20 hertz. However, marine biologists at the Woods Hole Oceanographic Institution reported in the New Scientist in December 2004 that they had been tracking a whale in the North Pacific for 12 years that was "singing" at 52 Hz. The scientists are currently unable to explain this dramatic difference from the norm; however, they are sure the whale is a baleen and extremely unlikely to be a new species, suggesting that currently known species may have a wider vocal range than previously thought.

Most other whales and dolphins produce sounds of varying degrees of complexity. Of particular interest is the Beluga (the "sea canary") which produces an immense variety of whistles, clicks and pulses.

Human interaction

Voyager Golden Records carried whale songs into outer space with other sounds representing planet Earth.

Though some observers suggest that undue fascination has been placed on the whales' songs simply because the animals are under the sea, most marine mammal scientists believe that sound plays a particularly vital role in the development and well-being of cetaceans. It may be argued those against whaling have anthropomorphized the behaviour in an attempt to bolster their case. Conversely pro-whaling nations are perhaps disposed to downplay the meaning of the sounds, noting for example that little account is taken of the "moo" of cattle.

Researchers use hydrophones (often adapted from their original military use in tracking submarines) to ascertain the exact location of the origin of whale noises. Their methods allow them also to detect how far through an ocean a sound travels. Research by Dr Christopher Clark of Cornell University conducted using thirty years worth of military data showed that whale noises travel up to 3,000 km. As well as providing information about song production, the data allows researchers to follow the migratory path of whales throughout the "singing" (mating) season.

Prior to the introduction of human noise production, Clark says the noises may have travelled right from one side of an ocean to the other. His research indicates that ambient noise from boats is doubling each decade. This has the effect of reducing the range at which whale noises can be heard. Those who believe that whale songs are significant to the continued well-being of whale populations are particularly concerned by this increase in ambient noise. Other research has shown that increased boat traffic in, for example, the waters off Vancouver, has caused some Orca to change the frequency and increase the amplitude of their sounds, in an apparent attempt to make themselves heard. Environmentalists fear that such boat activity is putting undue stress on the animals as well as making it difficult to find a mate.

Selected discography

• Songs of the Humpback Whale (SWR 118) was originally released in 1970 by CRM Records from recordings made by Roger Payne, Frank Watlington and others. The LP was later re-released by Capitol Records, published in a flexible format in the National Geographic Society magazine, Volume 155, Number 1, in January 1979 and released on CD by BGO-Beat Goes On in 2001.
• Deep Voices: The Second Whale Record (Capitol Records ST-11598) was released on LP in 1977 from additional recordings made by Roger Payne, and re-released on CD in 1995 by Living Music. It includes recordings of humpbacks, blues, and rights.
• Northern Whales (MGE 19) was released by Music Gallery Editions from recordings made by Pierre Ouellet, John Ford, and others affiliated with Interspecies Music and Communication Research. It includes recordings of belugas, narwhals, orca, and bearded seals.
• Sounds of the Earth: Humpback Whales (Oreade Music) was released on CD in 1999.
• Rapture of the Deep: Humpback Whale Singing (Compass Recordings) was released on CD in 2001.
