This image was copied from wikipedia:en. The original description was: Image:Internet map 1024.jpg

Summary

I created this small partial map of the Internet from the 2005- 01-15 data found here using a slightly different rendering technique than was used to generate the maps there. Each line is drawn between two nodes, representing two IP addresses. The length of the lines are indicative of the delay between those two nodes. This graph represents less than 30% of the Class C networks reachable by the data collection program in early 2005. Lines are colour-coded according to their corresponding RFC 1918 allocation as follows:

  • Dark blue: net, ca, us
  • Green: com, org
  • Red: mil, gov, edu
  • Yellow: jp, cn, tw, au, de
  • Magenta: uk, it, pl, fr
  • Gold: br, kr, nl
  • White: unknown

Big BIG HUGE (probably unusable in articles) version can be found at .

Русский: * Тёмно-синий: net, ca, us
  • Зелёный: com, org
  • Красный: mil, gov, edu
  • Жёлтый: jp, cn, tw, au, de
  • Розовый: uk, it, pl, fr
  • Сине-зелёный: br, kr, nl
  • Белый: не определено
