Image:Transistor 3d xsection.png
From Wikipedia, the free encyclopedia
Size of this preview: 628 × 480 pixels
Full resolution (640 × 489 pixels, file size: 919 KB, MIME type: image/png)
Summary
Cross-section through a MOS transistor (metallic layers and dielectric removed for clarity)
Self-made image, made using my own software. As far as I'm concerned, you can do whatever you like with this picture.
Licensing
I, the copyright holder of this work, hereby release it into the public domain. This applies worldwide. In case this is not legally possible, |
