Image:Activation energy.svg

From Wikipedia, the free encyclopedia

Activation_energy.svg‎ (SVG file, nominally 929 × 743 pixels, file size: 21 KB)

Wikimedia Commons logo This is a file from the Wikimedia Commons. The description on its description page there is shown below.
Commons is a freely licensed media file repository. You can help.

Summary

Illustration of change in activation energy caused by a catalyst. Made by me in Inkscape by tracing the original image by Vinay.bhat, who holds the copyright but has released all rights.

Description of original image:

Activation energies Ea(X→Y) or 'Ea(Y→X)' need to be supplied to initiate the reactions X→Y or Y→X, respectively. When the catalyst is added, the activation energy decreases. However the Enthalpy change, ΔH (Thermodynamic factor) between X and Y remain constant. The image is created by me.
