Lava

2008/9 Schools Wikipedia Selection. Related subjects: Mineralogy

Lava is molten rock expelled by a volcano during an eruption. When first expelled from a volcanic vent, it is a liquid at temperatures from 700 °C to 1,200 °C (1,300 °F to 2,200 °F). Although lava is quite viscous, with about 100,000 times the viscosity of water, it can flow great distances before cooling and solidifying, because of its thixotropic and shear thinning properties.

A lava flow is a (moving) outpouring of lava, which is created during a non-explosive effusive eruption. When it has stopped moving, lava solidifies to form igneous rock. The term lava flow is commonly shortened to lava. Explosive eruptions produce a mixture of volcanic ash and other fragments called tephra, rather than lava flows. The word 'lava' comes from Italian, and is probably derived from the Latin word labes which means a fall or slide. The first use in connection with extruded magma (molten rock below the earth's surface) was apparently in a short account written by Francesco Serao on the eruption of Vesuvius between May 14 and June 4, 1737. Serao described "a flow of fiery lava" as an analogy to the flow of water and mud down the flanks of the volcano following heavy rain.

Lava composition

In general, the composition of a lava determines its behaviour more than the temperature of its eruption. Igneous rocks, which form lava flows when erupted, can be classified into three chemical types; felsic, intermediate, and mafic. These classes are primarily chemical; however, the chemistry of lava also tends to correlate with the magma temperature, its viscosity and its mode of eruption.

Felsic lavas such as rhyolite and dacite typically form lava spines, lava domes or 'coulees' (which are thick, short lavas) and are associated with pyroclastic (fragmental) deposits. Most felsic lava flows are extremely viscous, and typically fragment as they extrude, producing blocky autobreccias. The high viscosity and strength are the result of their chemistry, which is high in silica, aluminium, potassium, sodium, and calcium, forming a polymerized liquid rich in feldspar and quartz, which thus has a higher viscosity than other magma types. Felsic magmas can erupt at temperatures as low as 650 to 750 °C. Unusually hot (>950 °C) rhyolite lavas, however, may flow for distances of many tens of kilometres, such as in the Snake River Plain of the northwestern United States.

Intermediate or andesitic lavas are lower in aluminium and silica, and usually somewhat richer in magnesium and iron. Intermediate lavas form andesite domes and block lavas, and may occur on steep composite volcanoes, such as in the Andes. Poorer in aluminium and silica than felsic lavas, and also commonly hotter (in the range of 750 to 950 °C), they tend to be less viscous. Greater temperatures tend to destroy polymerized bonds within the magma, promoting more fluid behaviour and also a greater tendency to form phenocrysts. Higher iron and magnesium tends to manifest as a darker groundmass, and also occasionally amphibole or pyroxene phenocrysts.

Mafic or basaltic lavas are typified by their high ferromagnesian content, and generally erupt at temperatures in excess of 950 °C. Basaltic magma is high in iron and magnesium, and has relatively lower aluminium and silica, which taken together reduces the degree of polymerization within the melt. Owing to the higher temperatures, viscosities can be relatively low, although still thousands of times more viscous than water. The low degree of polymerization and high temperature favors chemical diffusion, so it is common to see large, well-formed phenocrysts within mafic lavas. Basalt lavas tend can produce low-profile shield volcanoes or ' flood basalt fields', because the fluidal lava flows for long distances from the vent. The thickness of a basalt lava, particularly on a low slope, may be much greater than the thickness of the moving lava flow at any one time, because basalt lavas may 'inflate' by supply of lava beneath a solidified crust. Most basalt lavas are of a'a or 'pahoehoe' types, rather than block lavas. Underwater they can form 'pillow lavas', which are rather similar to entrail-type pahoehoe lavas on land.

Ultramafic lavas such as komatiite and highly magnesian magmas which form boninite take the composition and temperatures of eruptions to the extreme. Komatiites contain over 18% magnesium oxide, and are thought to have erupted at temperatures of 1600 °C. At this temperature there is no polymerization of the mineral compounds, creating a highly mobile liquid with viscosity as low as that of water. Most if not all ultramafic lavas are no younger than the Proterozoic, with a few ultramafic magmas known from the Phanerozoic. No modern komatiite lavas are known, as the Earth's mantle has cooled too much to produce highly magnesian magmas.

Lava behaviour

The viscosity of lava is important because it determines how the lava will behave. Lavas with high viscosity are rhyolite, dacite, andesite and trachyte, with cooled basaltic lava also quite viscous; those with low viscosities are freshly erupted basalt, carbonatite and occasionally andesite.

Highly viscous lava shows the following behaviors:

• tends to flow slowly, clog, and form semi-solid blocks which resist flow
• tends to entrap gas, which form vesicles (bubbles) within the rock as they rise to the surface
• correlates with explosive or phreatic eruptions and is associated with tuff and pyroclastic flows

Highly viscous lavas do not usually flow as liquid, and usually form explosive fragmental ash or tephra deposits. However, a degassed viscous lava or one which erupts somewhat hotter than usual may form a lava flow.

Lava with low viscosity shows the following behaviors:

• tends to flow easily, forming puddles, channels, and rivers of molten rock
• tends to easily release bubbling gases as they are formed
• eruptions are rarely pyroclastic and are usually quiescent
• volcanoes tend to form broad shields rather than steep cones

There are three forms of low-viscosity lava flows: ʻaʻā, pāhoehoe, and pillow lava. They are described in relation to basaltic flows from Hawaii, shown in the following sections.

Lavas also may contain many other components, sometimes including solid crystals of various minerals, fragments of exotic rocks known as xenoliths and fragments of previously solidified lava.

Volcanic morphologies

The physical behaviour of lava creates the physical forms of a lava flow or volcano. More fluid basaltic lava flows tend to form flat sheet-like bodies, whereas viscous rhyolite lava flows forms knobbly, blocky masses of rock.

General features of volcanology can be used to classify volcanic edifices and provide information on the eruptions which formed the lava flow, even if the sequence of lavas have been buried or metamorphosed.

The ideal lava flow will have a brecciated top, either as pillow lava development, autobreccia and rubble typical of ʻaʻā and viscous flows, or a vesicular or frothy carapace such as scoria or pumice. The top of the lava will tend to be glassy, having been flash frozen in contact with the air or water.

The centre of a lava is commony massive and crystalline, flow banded or layered, with microscopic groundmass crystals. The more viscous lava forms tend to show sheeted flow features, and blocks or breccia entrained within the sticky lava. The crystal size at the centre of a lava will in general be greater than at the margins, as the crystals have more time to grow.

The base of a lava may show evidence of hydrothermal activity if the lava flowed across moist or wet substrates. The lower part of the lava may have vesicles, perhaps filled with minerals ( amygdules). The substrate upon which the lava has flowed may show signs of scouring, it may be broken or disturbed by the boiling of trapped water, and in the case of soil profiles, may be baked into a brick-red terracotta.

Discriminating between an intrusive sill and a lava flow in ancient rock sequences can be difficult. However, some sills do not usually have brecciated margins, and may show a weak metamorphic aureole on both the upper and lower surface, whereas a lava will only bake the substrate beneath it. However, it is often difficult in practise to identify these metamorphic phenomenon because they are usually weak and restricted in size. Peperitic sills intruded into wet sedimentary rocks, commonly do not bake upper margins and have upper and lower autobreccias, closely similar to lavas.

ʻAʻā

ʻAʻā (also spelled aa, aʻa, ʻaʻa and a-aa, pronounced [ˈʔɑʔɑː] in Hawaiian English, from Hawaiian meaning "stony with rough lava", but also to "burn" or "blaze") is one of three basic types of flow lava. ʻAʻā is basaltic lava characterized by a rough or rubbly surface composed of broken lava blocks called clinker.

The loose, broken, and sharp, spiny surface of an ʻaʻā flow makes hiking difficult and slow. The clinkery surface actually covers a massive dense core, which is the most active part of the flow. As pasty lava in the core travels downslope, the clinkers are carried along at the surface. At the leading edge of an ʻaʻā flow, however, these cooled fragments tumble down the steep front and are buried by the advancing flow. This produces a layer of lava fragments both at the bottom and top of an ʻaʻā flow.

Accretionary lava balls as large as 3 m (10 ft) are common on ʻaʻā flows. ʻAʻā is usually of higher viscosity than pāhoehoe. Pāhoehoe can turn into ʻaʻā if it becomes turbulent from meeting impediments or steep slopes.

The sharp, angled texture makes ʻaʻā a strong radar reflector, and can easily be seen from an orbiting satellite (bright on Magellan pictures).

ʻAʻā lavas typically erupt at temperatures of 1000 C to 1100 °C

Pāhoehoe

Pāhoehoe (also spelled pahoehoe, pronounced /pəˌhoʊeˈhoʊe/, Hawaiian English, from Hawaiian, meaning "smooth, unbroken lava") is basaltic lava that has a smooth, billowy, undulating, or ropy surface. These surface features are due to the movement of very fluid lava under a congealing surface crust.

A pāhoehoe flow typically advances as a series of small lobes and toes that continually break out from a cooled crust. It also forms lava tubes where the minimal heat loss maintains low viscosity. The surface texture of pāhoehoe flows varies widely, displaying all kinds of bizarre shapes often referred to as lava sculpture. With increasing distance from the source, pāhoehoe flows may change into ʻaʻā flows in response to heat loss and consequent increase in viscosity. Pahoehoe lavas typically have a temperature of 1100 to 1200 °C.

The rounded texture makes pāhoehoe a poor radar reflector, and is difficult to see from an orbiting satellite (dark on Magellan pictures).

Pillow lava

Pillow lava is the rock type typically formed when lava emerges from an underwater volcanic vent or a lava flow enters the ocean. However, pillow lava can also form when lava is erupted beneath thick glacial ice. The viscous lava gains a solid crust on contact with the water, and this crust cracks and oozes additional large blobs or "pillows" as more lava emerges from the advancing flow. Since the majority of Earth's surface is covered by water, and most volcanoes are situated near or under it, pillow lava is very common.

Lava landforms

Because it is formed from viscous molten rock, lava flows and eruptions create distinctive formations, landforms and topographical features from the macroscopic to the microscopic.

Volcanoes

Volcanoes are the primary landforms built by repeated eruptions of lava and ash over time. They range in shape from shield volcanoes with broad, shallow slopes formed from predominantly effusive eruptions of relatively fluid basaltic lava flows, to steeply-sided stratovolcanoes (also known as composite volcanoes) made of alternating layers of ash and more viscous lava flows typical of intermediate and felsic lavas.

A caldera, which is a large subsidence crater, can form in a stratovolcano, if the magma chamber is partially or wholly emptied by large explosive eruptions; the summit cone no longer supports itself and thus collapses in on itelf afterwards. Such features may include volcanic crater lakes and lava domes after the event. However, calderas can also form by non-explosive means such as gradual magma subsidence. This is typical of many shield volcanoes.

Cinder and spatter cones

Cinder cones and spatter cones are small-scale features formed by lava accumulation around a small vent on a volcanic edifice. Cinder cones are formed from tephra or ash and tuff which is thrown from an explosive vent. Spatter cones are formed by accumulation of molten volcanic slag and cinders ejected in a more liquid form.

Kīpukas

Another Hawaiian English term derived from the Hawaiian language, a kīpuka denotes an elevated area such as a hill, ridge or old lava dome inside or downslope from an area of active volcanism. New lava flows will cover the surrounding land, isolating the kīpuka so that it appears as a (usually) forested island in a barren lava flow.

Lava domes

Lava domes are formed by the extrusion of viscous felsic magma. They can form prominent rounded protuberances, such as at Valles Caldera. As a volcano extrudes silicic lava, it can form an inflation dome, gradually building up a large, pillow-like structure which cracks, fissures, and may release cooled chunks of rock and rubble. The top and side margins of an inflating lava dome tend to be covered in fragments of rock, breccia and ash.

Examples of lava dome eruptions include the Novarupta dome, and successive lava domes of Mount St Helens.

Lava tubes

Lava tubes are formed when a flow of relatively fluid lava cools on the upper surface sufficiently to form a crust. Beneath this crust, which by dint of being made of rock is an excellent insulator, the lava can continue to flow as a liquid. When this flow occurs over a prolonged period of time the lava conduit can form a tunnel-like aperture or lava tube, which can conduct molten rock many kilometres from the vent without cooling appreciably. Often these lava tubes drain out once the supply of fresh lava has stopped, leaving a considerable length of open tunnel within the lava flow.

Lava tubes are known from the modern day eruptions of Kīlauea, and significant, extensive and open lava tubes of Tertiary age are known from North Queensland, Australia, some extending for 15 kilometres.

Lava cascades and fountains

The eruptions of lava are sometimes attended by peculiarities which impart to them much additional grandeur. Instances have occurred in which the fiery stream has plunged over a sheer precipice of immense height, so as to produce a glowing cascade exceeding (in breadth and perpendicular descent) the celebrated Niagara Falls. In other cases, the lava, instead of at once flowing down the sides of the mountain, has been first thrown up into the air as a fiery fountain several hundred feet in height (see Volcanic cone).

Lava lakes

Rarely, a volcanic cone may fill with lava but not erupt. Lava which pools within the caldera is known as a lava lake. Lava lakes do not usually persist for long, either draining back into the magma chamber once pressure is relieved (usually by venting of gases through the caldera), or by draining via eruption of lava flows or pyroclastic explosion.

There are only a few sites in the world where permanent lakes of lava exist. These include:

• Mount Erebus, Antarctica
• Pu'u 'Ō'ō and formerly Kīlauea volcanoes, Hawaiʻi
• Erta Ale, Ethiopia
• Nyiragongo, Democratic Republic of Congo

Unusual lavas

Four types of unusual volcanic rocks have been recognised as erupting onto the surface of the Earth:

• Carbonatite and natrocarbonatite lavas are known from Ol Doinyo Lengai volcano in Tanzania, which is the sole example of an active carbonatite volcano.
• Copper sulfide bearing lavas have been recognised from Chile and Bolivia
• Iron oxide lavas are thought to be the source of the iron ore at Kiruna, Sweden, erupted in the Proterozoic, and in Chile associated with highly alkaline igneous rocks
• Olivine nephelinite lavas are a unique type of lava that is thought to have come from much deeper in the mantle of the Earth.

The term "lava" can also be used to refer to molten "ice mixtures" in eruptions on the icy satellites of the Solar system's gas giants.

Hazards

Lava flows are enormously destructive to property in their path but generally move slowly enough for people to get out of their way, so casualties caused directly by active lava flows are rare. Nevertheless injuries and deaths have occurred, either because people had their escape route cut off, because they got too close to the flow or, more rarely, if the lava flow front travelled too quickly.

This notably happened during the eruption of Nyiragongo in Zaire (now Democratic Republic of Congo) on 10 January 1977 when the crater wall was breached during the night and the fluid lava lake in it drained out in less than an hour. Flowing down the steep slopes of the volcano at up to 60 miles per hour (100 km/h), the lava swiftly overwhelmed several villages whilst their residents were asleep. As a result of this disaster, the mountain was designated a Decade Volcano in 1991.

Deaths attributed to volcanoes frequently have a different cause, for example volcanic ejecta, pyroclastic flow from a collapsing lava dome, lahars, poisonous gases that travel ahead of lava, or explosions caused when the flow comes into contact with water.

Towns destroyed by lava flows

• Kaimū, Hawaiʻi Destroyed by the eruption of the Kīlauea volcano in 1990. (abandoned)
• Kalapana, Hawaiʻi Destroyed by the eruption of the Kīlauea volcano in 1990. (abandoned)
• Kapoho, Hawaiʻi Destroyed by a lava flow from an eruption of Kīlauea on January 28, 1960. (abandoned)
• Keawaiki, Hawaiʻi (abandoned)
• Koaʻe, Hawaiʻi (abandoned)
• San Sebastiano al Vesuvio, Italy Destroyed in 1944 by the most recent eruption of Mount Vesuvius during the Allies' occupation of southern Italy. (rebuilt)
• Cagsawa, Philippines

Towns partially destroyed by lava flows

• Catania, Italy, in the eruption Mount Etna in 1669 (rebuilt)
• Goma, Democratic Republic of Congo, in the eruption of Nyiragongo in 2002
• Heimaey, Iceland, in the 1973 Eldfell eruption (rebuilt)
• Royal Gardens, Hawaiʻi, by the eruption of Kilauea in 1986-87 (abandoned)
• Parícutin (village after which the volcano was named) and San Juan Parangaricutiro, Mexico, by Parícutin from 1943-1952.

Towns destroyed by tephra

• Pompeii, Italy in the eruption Mount Vesuvius in 79 AD
• Herculaneum, Italy in the eruption Mount Vesuvius in 79 AD
